Typically for medium--term vehicle graphics, total vehicle covering, signs, etc.
Composition
|
PVC
|
|
Type
|
Calendered monomeric soft PVC film, clear, glossy, perfect ink receptivity
|
|
Thickness
|
80±5 µm(without liner and adhesive)
|
|
Tensile Strength
|
≥25N/㎡
|
|
Elongation
|
≥150 (MD/CD)
|
|
Surface Tension
|
≥35dn/cm
|
|
Shrinkage
|
Adhere to silicon paper, max.1mm shrinkage in cross and vertical direction
|
|
Adhesive
|
|
Type
|
Solvent based pressure-sensitive acrylic, removable or permanent, clear
|
|
Weight
|
20±2 gsm (dried coated)
|
|
Initial Tack
|
≥600g/25mm (20min)
|
|
Holding Power
|
≥800g/25mm (24hrs)
|
|
Release Force
|
50-150g/50mm
|
|
Shear
|
≥1000Min
|
|
Liner
|
|
Type
|
One -side PE coated Kraft
|
|
Weight
|
100gsm
|
|
Humidity Resistance
|
Good
|
|
Applications
|
|
Available Width
|
0.914m, 1.07m, 1.27m, 1.37m, 1.52m
|
|
Available Length
|
50m, 100m
|
|
Service Temperature Range
|
-30 oC to +70 oC
|
|
Flammability
|
Self extinguishing
|
|
Removal
|
Cleanly removed in 6 months
|
|
Shelf Life
|
1 year when stored at 23 oC and 50% relative humidity.
|
|
Exterior Life Expectancy
|
1 year
|
|
Compatible Printers and Inks
|
Solvent, eco-solvent and UV curable printers and inks
|
